Details
Versatility & Efficiency:
- small space requirement
- movable container for the ground product
- powerful three-phase motors with surface cooling and high starting torque – suitable for continuous use
- service-free, constantly greased bearings
- extremely wear resistant, precision grinding discs for careful cutting of the material
Additional Information
| Voltage/frequency/phase | 208 V / 60 Hz / 3 |
|---|---|
| Motor power | 5.5 kW |
| Average grinding capacity | 3833 g/min |
| Hopper capacity | 30000 g |
| Grinding disc diameter Ø | 180 mm |
| Weight (kg) | 155.0000 |
| Dimensions (L X H X D) (mm) | 790 x 1600 x 1230 |
| Call For Price | Yes |
Operation:
- tight discharge chute for dust-reduced grinding
- hopper slider to interrupt the feeding of the product
- motor protection against electrical overload
- the grind adjustment cap provides precise, accurately repeatable control of the particle size
Design:
- large hopper
- integrated hopper magnets as a protection against metal in the product
- air cooling of grinder casing to reduce temperature (DK27)
