Details
Features:
- Dispenses chilled, still and sparkling water
- Substantially reduce costs of purchasing pre-bottled mineral waters
- Re-usable glass bottles in 425ml, 500ml, 750ml and 1 liter sizes
- Bottles can be personalized Save the environment - eliminate regular deliveries as well as the disposal of empty bottles and packaging
- High performance ice bank refrigeration system capable of delivering very high volumes of chilled water at low temperatures, particularly at peak demand times Power saving option to reduce electricity
- Eliminate any storage issues
- Purpose designed bottle washing trays designed to fit most commercial dishwashers
- Removable tap nozzles for ease of cleaning and sanitizing
- Stainless steel drip tray with plumb to waste option Integral CO2 bottle
Additional Information
| Dimensions (L X H X D) (mm) | 375 x 584 x 362 |
|---|---|
| Weight (kg) | 44.5000 |
| Minimum water pressure | 50 PSI |
| Maximum water pressure | 80 PSI |
| Minimum water flow | 80 US gallons/h |
| 20 Amp Socket | No |
| 15 Amp Socket | 15amp electrical socket (5-15) 120v/60hz (11 amps) |
| Call For Price | Yes |
Equipment Dimensions:
Width 14 3⁄4” Depth 14 1⁄4” Height 23” Cobra Tap: 19 1⁄2” (total tap height mounted)
*Maximum Counter thickness for mounting cobra tap 1 1⁄2” *Minimum Space Required for System: Height 29 1⁄2” Width 30” Depth 24”. Please note that the system is installed as an Under Counter unit. Alternatively it can be installed as a Counter Top system.
Countertop: (alternative option)
System is installed as one unit on the countertop with the dispense taps mounted on the front. Refer to Bottler V3-204
The following services are required to be supplied by the customer and must be available prior to installation:
1 potable 1/2” cold water supply terminating in a ½” ball valve, ½” female pipe thread. (ball valve must be accessible for service and installation).
*The Vivreau system incorporates back flow prevention, any additional back flow devices required by local or state code must also be supplied by the customer prior to installation.
