Details
Features:
- New improved modern designed dispense tap High performance icebank refrigeration system delivering 80 liters of cold water per hour
- Touch control dispense with hot water safety feature
- Can be installed in modular form to fit into the tightest of spaces
- Designed to fill sports bottles without the need for font extension
- Perfect water flow with zero splash
- Plumbed to waste flush fitting drip tray
- Waste container with alarm if waste provisions not available
- Removable dispense nozzle for improved hygiene
- Power saving option to reduce electricity consumption
- Anti-flood detection as standard
- Mavea descaling filter fitted as standard
Additional Information
| Dimensions (L X H X D) (mm) | 64 x 51 x 72 |
|---|---|
| Weight (kg) | 44.5000 |
| Minimum water pressure | 50 PSI |
| Maximum water pressure | 80 PSI |
| Minimum water flow | 80 US gallons/h |
| 20 Amp Socket | 20amp electrical socket (L6-20) 230v 60Hz (11 amps) |
| 15 Amp Socket | 15amp electrical socket (5-15) 120v/60hz (2 amps) |
| Call For Price | Yes |
Product Dispensed:
Advanced micro-filtered, chilled still and sparkling water
Application:
Designed typically to be installed within existing cabinet units in an office break area for staff refreshments
Equipment Dimensions:
Due to the fact that the equipment is installed in component part form, there are varying configurations for installation.
As a guideline, a cupboard to the following dimensions will be sufficient:
Length 2’6 Depth 2’ Height 2’10” Dispense Taps (Drilling templates attached) Dimensions Height 13” plus additional 6” clearance for operation
Please note that this system is installed as an under-counter unit. The following services are required to be supplied by the customer and must be available prior to installation: 1 potable ½” cold water supply terminating in a ½” ball valve, ½” female pipe thread. (ball valve must be accessible for service and installation).
*The Vivreau system incorporates back flow prevention, any additional back flow devices required by local or state code must also be supplied by the customer prior to installation. There should not be any other filters/pre-filters before the Vivreau system. Minimum water pressure 50 PSI Maximum pressure 80 PSI Minimum water flow 80 Gallons per hour 15amp electrical socket (5-15) 120v 60 Hz (2 amps) 20amp electrical socket (L6-20) 230v 60Hz (11 amps)
